MODULAR LUMINAIRE CORELINE PAN 2900-4300LM CCT DALI 300X1200

Philips CoreLine Panel 30x120 modular light for office spaces

Features

• Adjustable luminous flux: 2900 / 3100 / 3350 / 3600 / 4000 / 4300 lm
• Power: 22 / 31 W
• Luminous efficacy: 129 / 141 lm/W
• Adjustable color temperature: 3000 / 3500 / 4000 K
• Color rendering index: Ra80
• Beam angle: 90°
• Glare index UGR < 19 (office compatible)
• IP rating: front IP44, rear IP20
• IK rating: IK02
• DALI control
• Dimmable
• External driver
• Rotatable quick connector between panel and driver
• Tool-free suspension
• Chainable
• Can be suspended, surface-mounted or recessed
• Operating temperature: -10 ... +35 °C
• Dimensions: 30 x 120 cm
• Lifespan: 100,000 hours (L80)
• 5-year product warranty

Applications

• Offices, suitable for display screen work areas due to low UGR value
• General lighting
• Corridors
• Lobbies
• Damp areas

Philips CoreLine Panel is an extremely thin panel light for low ceilings. The light's uniform light surface creates pleasant illumination, and the light is very easy to install thanks to the quick connector. The light's UGR value is under 19, making it suitable for use in offices. Due to its IP44 rating, the light is suitable for use in damp areas. The light is DALI controllable and features adjustable luminous flux of 2900 / 3100 / 3350 / 3600 / 4000 / 4300 lm and color temperature of 3000 / 3500 / 4000 K. The light's beam angle is 90°. The product can be installed recessed, surface-mounted or suspended. The product's lifespan is 100,000 hours with a five-year product warranty.

Signify (formerly Philips Lighting) is a global market leader in lighting. Our portfolio includes LED lamps and luminaires, wireless control systems, and other lighting innovations for professional and home use. Sustainability values are at the core of Signify's business operations. This product description is an automated translation of the original Finnish description.
