BOREHOLE PUMP WATMAN PM 18-24 / VS 2/20 3-V (100m)

The 100 m 3-v UPPO-PYKE package includes a pre-dimensioned submersible borehole pump and cable. A lifting rope is available as an optional accessory.

UPPO-PYKE pumps are designed for clean and cold borehole water that may temporarily contain small amounts of sand (max. 100 g/m³, grain size max. 2.0 mm). The pump is suitable for domestic water supply and irrigation in single-family homes, holiday homes, agriculture, and industry.

Features

• Water-cooled Franklin electric motor with cable
• Fits a 4" borehole
• Easy to install and operate
• Also suitable for water lifting from ring wells or lakes
• Low operating costs
• Quiet operation
• Does not require a separate pump room
• Can be installed horizontally or vertically (for horizontal installation, contact Pumppulohja customer service)
• Optional accessories include cooling pipe and pump guard
• Rotation direction: counterclockwise when viewed from the outlet
• Integrated check valve: it is also recommended to install an external check valve
• Water temperature range: 0 °C – 40 °C
• 2-year warranty
• 1-phase 2W motors equipped with automatic starter
• The automatic starter prevents startup if voltage is too low, protecting the motor.
• If the pump becomes jammed, for example due to high sand content, the automatic starter briefly reverses the pump’s rotation, after which the rotation direction normalizes.

Pyke pumps are most commonly used with a pressure tank as a pressurized water system. When water consumption is low, the pressure tank and pressure switch can be replaced by a pressure controller (single-phase), which starts the pump immediately when the tap is opened and stops it when the tap is fully closed. They can also be operated manually for irrigation or pumping into open tanks.

This product description is an automated translation of the original Finnish description.
