HEATING PIPE PEXFLEX PLUS 2x63/200mm DUO PN6
Product code
3011186
PexFlex PLUS is our standard pipe and a true bestseller. It meets the energy efficiency requirements of most projects.
PexFlex Plus is known for its energy efficiency and ease of installation. The corrugated protective jacket and soft-cell polyurethane foam form an extremely flexible structure. A friction-reducing XPE cellular mat layer is installed between the pipe's protective jacket and the polyurethane, giving the product approximately 40% more flexibility. The product's durable construction and safe, easy installation ensure a calculated service life of up to 50 years for pipelines.
• Insulated twin-pipe system Ø25-75 mm
• Pressure class PN6
• Insulation material PUR
• Energy efficient – meets the requirements of most applications This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Pre-insulated plastic pipe (EC011704)
Number of inner pipes2
Material inner pipePE-Xa
Diffusion-proofyes
Diameter inner pipe63 mm
Wall thickness inner pipe5.8 mm
Diameter inner pipe 263 mm
Wall thickness inner pipe 25.8 mm
Colour inner pipeRed
Outer diameter mantle pipe200 mm
Material mantle pipeHigh-density polyethylene (HDPE)
Colour mantle pipeBlack
Insulating materialPolyurethane (PUR)
Max. operating pressure at 20 °C6 bar
Max. medium temperature (continuous)85 °C
Max. medium temperature (momentarily)95 °C
Product codes
SAPCNE354
HPAC3011186
PLC3011186
GTIN/EAN6415830111866
Manufacturer part number3011186
Vendor material number3011186
Basic information
Package measurements (L x W x H)1000 x 0 x 0 mm
Package volume60.331 l
Package weight4.5 kg
Base unitMeter
Package units145
Package contents–
UNSPSC40141914
BrandRAUHEAT
VendorRAUHEAT OY
Documents (12)
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)16.965
GWP, unitMeter
Source for GWP dataEPD
