LED STRIP 4K IP20 24V 4,8W/M 677lM/M

Product code
4133328

5-meter reel of LED tape with 320 surface-mount LEDs. The tape has a 3M adhesive backing on the reverse side and can be cut every 125 mm. Both ends of the LED tape are pre-soldered with 3 meters of white-gray supply cable.

Power consumption: 4.8W/m / 157 lm/w.

Features
  • structure: 5m LED tape with 3M tape, connection cables 3m
  • dimensions: width 8mm, height approx. 1.5mm
  • color: 4000K
  • power: 4.8 W/m
  • voltage: 24V
  • light emission angle: 120°
  • luminous flux: 677 lm/m
  • installation: Adhesive mounting to surface
  • wiring: Parallel connection
  • protection rating: IP20
This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Light ribbon/-hose/-strip (EC002706)
ModelStrip
Mounting methodSurface mounting
Lamp typeLED not exchangeable
Number of nodes per meter64
Lamp power per meter4.8 W
Luminous flux per meter677 lm
Voltage typeDC
Beam angle120 °
Type of control gearLED operating device voltage-controlled
Degree of protection (IP)IP20
Protection class according to IEC 61140III
Max. system power24 W
Colour of lightWhite
Colour temperature4000 - 4000 K
Colour rendering index CRI80-89

Product codes

SAPCLA203
STK4133328
PLC4133328
GTIN/EAN6438524001694
Manufacturer part number10001694
Vendor material number4133328

Basic information

Package measurements (L x W x H)285 x 245 x 23 mm
Package volume1.606 l
Package weight0.21 kg
Base uniteach
Package units1 / 100
Package contents
UNSPSC39112102
BrandSAAS INSTRUMENTTI
VendorSAAS INSTRUMENTTI OY

Environment and safety

Manufacturer

NameSaas Instrumentti Oy
Postal addressHenry Fordin katu 5 B, 00150 Helsinki, Suomi
Safety manual
