LED STRIP 4K IP20 24V 4,8W/M 677lM/M
Product code
4133328
5-meter reel of LED tape with 320 surface-mount LEDs. The tape has a 3M adhesive backing on the reverse side and can be cut every 125 mm. Both ends of the LED tape are pre-soldered with 3 meters of white-gray supply cable.
Power consumption: 4.8W/m / 157 lm/w.
Features- structure: 5m LED tape with 3M tape, connection cables 3m
- dimensions: width 8mm, height approx. 1.5mm
- color: 4000K
- power: 4.8 W/m
- voltage: 24V
- light emission angle: 120°
- luminous flux: 677 lm/m
- installation: Adhesive mounting to surface
- wiring: Parallel connection
- protection rating: IP20
Product details
Technical specifications
Product class (ETIM)Light ribbon/-hose/-strip (EC002706)
ModelStrip
Mounting methodSurface mounting
Lamp typeLED not exchangeable
Number of nodes per meter64
Lamp power per meter4.8 W
Luminous flux per meter677 lm
Voltage typeDC
Beam angle120 °
Type of control gearLED operating device voltage-controlled
Degree of protection (IP)IP20
Protection class according to IEC 61140III
Max. system power24 W
Colour of lightWhite
Colour temperature4000-4000 K
Colour rendering index CRI80-89
Product codes
SAPCLA203
STK4133328
PLC4133328
GTIN/EAN6438524001694
Manufacturer part number10001694
Vendor material number4133328
Basic information
Package measurements (L x W x H)285 x 245 x 23 mm
Package volume1.606 l
Package weight0.21 kg
Base uniteach
Package units1 / 100
Package contents–
UNSPSC39112102
BrandSAAS INSTRUMENTTI
VendorSAAS INSTRUMENTTI OY
Documents (5)
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)2.73
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490
Manufacturer
NameSaas Instrumentti Oy
Websitehttps://saas.fi/yhteys/
Postal addressHenry Fordin katu 5 B, 00150 Helsinki, Suomi
Safety manual
