LED STRIP STRIP PRO MINI 3K 24V

Product code
4128102

Saas Strip Pro Mini 3000 K is a professional-grade LED strip. The product comes on a 5-meter reel with 120 surface-mount LEDs. The strip has a 3M adhesive backing on the reverse side. It can be cut every 50 mm, and both ends are pre-soldered with 3 meters of supply cable. The power consumption of the LED strip is approximately 48 W / 5 m.

Features
  • Construction: 5 m LED strip with 3M tape, pre-soldered connectors 3 m, 24 V
  • Dimensions: width 4 mm, height approximately 2 mm
  • Color: 3000 K
  • Power: 9.6 W/m
  • Voltage: 24V
  • Beam angle: 120°
  • Luminous flux: approx. 600 lm/m
  • Installation: Adhesive mounting to surface, must be installed into a heat sink profile (Highline Striprail Mini 4128104)
  • Connection: Parallel connection
  • Protection rating: IP20
This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Light ribbon/-hose/-strip (EC002706)
ModelStrip
Mounting methodSurface mounting
Lamp typeLED not exchangeable
Number of nodes per meter120
Number of nodes per foot36
Lamp power per meter9.6 W
Lamp power per foot2.88 W
Luminous flux per meter800 lm
Voltage typeDC
Lamp voltage24-24 V
Beam angle120 °
Type of control gearLED operating device voltage-controlled
Suitable for dimmerno
Exchangeable control gearyes
Rated lifetime L70/B50 at 25 °C30000 h

Product codes

SAPCDV818
STK4128102
PLC4128102
GTIN/EAN6438524001960
Manufacturer part number10000555
Vendor material number4128102

Basic information

Package measurements (L x W x H)285 x 245 x 15 mm
Package volume1.047 l
Package weight0.2 kg
Base uniteach
Package units1 / 10
Package contents
UNSPSC39112102
BrandSAAS INSTRUMENTTI
VendorSAAS INSTRUMENTTI OY

Environment and safety

Carbon footprint data

Carbon footprint of product manufacturing (A1–A3 GWP value)2.6
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490

Manufacturer

NameSaas Instrumentti Oy
Postal addressHenry Fordin katu 5 B, 00150 Helsinki, Suomi
Safety manual
