CAM SWITCH 0-1, 1-P 10A PANEL 16/22,5mm
Product code
3607313
Open-close switches. Nose switch for P110 0-1 1N 10A quick attachment to central hole Ř22.5mm. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Control switch (EC002611)
Type of switchOn/off switch
Number of poles1
Max. rated operation voltage Ue AC440 V
Rated permanent current Iu10 A
Number of switch positions2
With zero (off) positionyes
With retraction in 0-positionno
Device constructionBuilt-in device
Suitable for distribution board installationyes
Suitable for intermediate mountingyes
Type of control elementShort rotary handle
Front shield size30x30 mm
Degree of protection (IP), front sideIP66
Degree of protection (NEMA), front sideOther
Product codes
SAPADK456
STK3607313
PLC3607313
GTIN/EAN4024537006218
Manufacturer part numberP110-61001-219M1
Vendor material number3607313
Basic information
Package measurements (L x W x H)110 x 50 x 50 mm
Package volume0.275 l
Package weight0.03 kg
Base uniteach
Package units1
Package contents–
UNSPSC39122209
BrandSÄLZER
VendorUTU OY
