CAM SWITCH 1 POLE 10A 2-HOLE PANEL/MINI
Product code
3607311
From our lever switch range, you can find rotary and lever-type control switches suitable for loading, control, and instrumentation circuits. From our key switch range, you will find versatile products for panel, base, instrument panel, and DIN mounting, housed within rated current ranges of 10 to 315 A. We can also supply customer-specific and customized key switches with rated currents of 20 and 25 A, allowing the customer to freely define the switching function and engraving on the plates. From our modular lever switch range, you will find products suitable for control and network switching with rated currents of 25 to 63 A. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Control switch (EC002611)
Type of switchOn/off switch
Number of poles1
Max. rated operation voltage Ue AC440 V
Rated permanent current Iu10 A
Number of switch positions2
With zero (off) positionyes
With retraction in 0-positionno
Device constructionBuilt-in device
Suitable for distribution board installationyes
Suitable for intermediate mountingno
Complete device in housingno
Type of control elementShort rotary handle
Front shield size30x30 mm
Degree of protection (IP), front sideIP66
Degree of protection (NEMA), front sideOther
Product codes
SAPADK455
STK3607311
PLC3607311
GTIN/EAN4024537006201
Manufacturer part numberP110-61001-003M1
Vendor material number3607311
Basic information
Package measurements (L x W x H)50 x 110 x 50 mm
Package volume0.275 l
Package weight0.09 kg
Base uniteach
Package units1
Package contents–
UNSPSC39122209
BrandSÄLZER
VendorUTU OY
