CAM SWITCH 2 POLE 20A 4-HOLE PANEL
Product code
3607152
From our range of lever switch contacts, you can find rotary and lever-type control switches suitable for loading, control, and instrumentation circuits. From our range of toggle switch contacts, you can find versatile products for panel, base, instrument panel, and DIN mounting, housed in nominal current ranges of 10 to 315 A. We can also supply customer-specific and customized toggle switches with nominal currents of 20 and 25 A, allowing the customer to freely define the switching function and engraving on the plates. From our range of modular lever switches, you can find products suitable for control and network switching with nominal currents of 25 to 63 A. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Control switch (EC002611)
Type of switchOn/off switch
Number of poles2
Max. rated operation voltage Ue AC690 V
Rated permanent current Iu20 A
Number of switch positions2
With zero (off) positionyes
With retraction in 0-positionno
Suitable for distribution board installationyes
Suitable for intermediate mountingno
Complete device in housingno
Type of control elementShort rotary handle
Front shield size48x48 mm
Degree of protection (IP), front sideIP66
Degree of protection (NEMA), front sideOther
Product codes
SAPADK431
STK3607152
PLC3607152
GTIN/EAN4024537006676
Manufacturer part numberP220-61002-003M1
Vendor material number3607152
Basic information
Package measurements (L x W x H)110 x 50 x 50 mm
Package volume0.275 l
Package weight0.09 kg
Base uniteach
Package units1
Package contents–
UNSPSC39122209
BrandSÄLZER
VendorUTU OY
