CAM SWITCH 3 POLE 20A 4-HOLE PANEL
Product code
3607154
Control switches
Open - Closed switches This product description is an automated translation of the original Finnish description.
Open - Closed switches This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Control switch (EC002611)
Type of switchOn/off switch
Number of poles3
Max. rated operation voltage Ue AC690 V
Rated permanent current Iu20 A
Number of switch positions2
With zero (off) positionyes
With retraction in 0-positionno
Device constructionSurface mounted device
Suitable for distribution board installationyes
Suitable for intermediate mountingno
Complete device in housingno
Type of control elementShort rotary handle
Front shield size48x48 mm
Degree of protection (IP), front sideIP66
Degree of protection (NEMA), front sideOther
Product codes
SAPAAR194
STK3607154
PLC3607154
GTIN/EAN4024537006690
Manufacturer part numberP220-61003-003M1
Vendor material number3607154
Basic information
Package measurements (L x W x H)110 x 50 x 50 mm
Package volume0.275 l
Package weight0.126 kg
Base uniteach
Package units1 / 10
Package contents–
UNSPSC39122209
BrandSÄLZER
VendorUTU OY
The country of origin stated by the supplierFinland
