NET CHANGE-OVER SWITCH H406 1-0-2 4P 63A ENCL. IP66
Product code
3607006
Enclosed network switch for properties where electricity supply needs to be ensured by an aggregate/generator feed in case of power outages in the distribution network. The enclosure enables versatile installation of the product in various environments outside main switchgear and similar distribution centers. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Off-load switch (EC001105)
ModelOther
Number of poles8
With zero (off) positionyes
With retraction in 0-positionno
Rated permanent current Iu63 A
Rated operation power at AC-3, 400 V18.5 kW
Degree of protection (IP), front sideIP66
Degree of protection (NEMA), front sideOther
Suitable for distribution board installationno
Type of control elementShort rotary handle
Type of electrical connection of main circuitScrew connection
Product codes
SAPAMM971
STK3607006
PLC3607006
GTIN/EAN4024537337152
Manufacturer part numberH406-71400-976H1
Vendor material number3607006
Basic information
Package measurements (L x W x H)345 x 265 x 300 mm
Package volume27.428 l
Package weight4.1 kg
Base uniteach
Package units1
Package contents1 each
UNSPSC39122217
BrandSÄLZER
VendorUTU OY
