REVERSING SWITCH P220 1>0<2 3P 20A 4-HOLE

Product code
3607003
From our lever switch range, you can find rotary and lever-type control switches suitable for loading, control, and instrumentation circuits. From our key switch range, you will find versatile products for panel, base, instrument panel, and DIN mounting, housed within rated current ranges of 10 to 315 A. We can also supply customer-specific and customized key switches with rated currents of 20 and 25 A, allowing the customer to freely define the switching function and engraving on the plates. From our modular lever switch range, you will find products suitable for control and network switching with rated currents of 25 to 63 A. This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Off-load switch (EC001105)
ModelReversing pole-switch
Number of poles5
With zero (off) positionyes
With retraction in 0-positionyes
Rated permanent current Iu20 A
Rated operation current Ie at AC-3, 400 V20 A
Rated operation power at AC-3, 400 V5.5 kW
Degree of protection (IP), front sideIP66
Degree of protection (NEMA), front sideOther
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as change-over contact0
Suitable for distribution board installationyes
Suitable for intermediate mountingno
Complete device in housingno

Product codes

SAPATB524
STK3607003
PLC3607003
GTIN/EAN4024537053113
Manufacturer part numberP220-61253-003M1
Vendor material number3607003

Basic information

Package measurements (L x W x H)110 x 50 x 50 mm
Package volume0.275 l
Package weight0.13 kg
Base uniteach
Package units1
Package contents
UNSPSC39122209
BrandSÄLZER
VendorUTU OY

Documents (5)

Environment and safety

Manufacturer

NameUTU Oy
Postal addressAhjontie 1, 28400 Ulvila
