PRESS T-PIECE REDUCER CU 15x12x12 CHROME SANHA

Product code
1543063
Copper compression fitting system suitable for installation with M, V, and SA profiles up to 54 mm. Pressure class PN16, black EPDM O-ring resistant to glycol. Operating temperature: -30°C to 120°C. Components compatible with EN1057 copper pipes. Threaded parts manufactured from phosphor bronze (CuSi), a zinc and lead-free material. Phosphor bronze components can be installed with Sanha acid-resistant pipes. Leak-free without compression. Always perform a leak test before pressure testing. This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Fitting with 3 connections (EC003025)
Material connection 1Copper
Surface protection connection 1Chromium-plated
ModelT-piece
Outer pipe diameter connection 115 mm
Connection 1Press sleeve
Outer pipe diameter connection 215 mm
Connection 2Press sleeve
Outer pipe diameter connection 312 mm
Connection 3Press sleeve

Product codes

SAPAMN098
HPAC1543063
PLC1543063
GTIN/EAN4021343219436
Manufacturer part number116130151212
Vendor material number116130151212

Basic information

Package measurements (L x W x H)63 x 42 x 18 mm
Package volume0.048 l
Package weight0.052 kg
Base uniteach
Package units1 / 10 / 150
Package contents
UNSPSC40172612
BrandSANHA
VendorSANHA POLSKA SP.ZO.O.

Environment and safety

Carbon footprint data

Carbon footprint of product manufacturing (A1–A3 GWP value)0.143
GWP, uniteach
Source for GWP dataEPD
