PRESS T-PIECE REDUCER CU 76,1x54x76,1 SANHA

Product code
1548275
Copper compression fitting system suitable for installation on 64mm - 108mm M and SA profile lips. Pressure class PN16, black EPDM O-ring resistant to glycol. Operating temperature: -30°C to 120°C. Components compatible with EN1057 copper pipes. Threaded parts manufactured from phosphor bronze (CuSi), a zinc and lead-free material. Phosphor bronze components can be installed with Sanha acid-resistant pipes. Leak-free without compression. Always perform a leak test before pressure testing. This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Fitting with 3 connections (EC003025)
Material connection 1Copper
ModelT-piece
Nominal diameter connection 1Other
Outer pipe diameter connection 176.1 mm
Connection 1Press sleeve
Nominal diameter connection 2Other
Outer pipe diameter connection 254 mm
Connection 2Press sleeve
Nominal diameter connection 3Other
Outer pipe diameter connection 376.1 mm
Connection 3Press sleeve

Product codes

SAPAPL604
HPAC1548275
PLC1548275
GTIN/EAN4021343176432
Manufacturer part number16130765476
Vendor material number16130765476

Basic information

Package measurements (L x W x H)171 x 143 x 95 mm
Package volume2.323 l
Package weight1.12 kg
Base uniteach
Package units1 / 6 / 270
Package contents
UNSPSC40172612
BrandSANHA
VendorSANHA POLSKA SP.ZO.O.

Environment and safety

Carbon footprint data

Carbon footprint of product manufacturing (A1–A3 GWP value)3.08
GWP, uniteach
Source for GWP dataEPD

Documents (1)

Sustainability brochures & documents
