LIGHT KIT SAVO TUDO WHITE 2500 MM 4000K
Product code
4161905
In the kitchen, there is a pre-installed wall switch to cut power from the existing distribution box or outlet to which the JOIN converter is connected. The converter's power cable is 2 meters long.
Each end of the light strip has a 2-meter power cable, allowing the light strip to be cut at the desired location if needed (e.g., for a range hood).
The JOIN branch cable is connected to the converter, and the light strip's power cable is connected to the branch cable.
The set includes:
JOIN converter
JOIN branch cable
white TUDO aluminum profile 2500mm with mounting brackets and end caps
TUDO LED light strip 4000K 2500mm (power cable 2000mm on each end) This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Light ribbon/-hose/-strip (EC002706)
ModelStrip
Mounting methodSurface mounting
Lamp typeLED not exchangeable
Lamp power per meter11.5 W
Luminaire efficacy173.9 lm/W
Voltage typeDC
Type of power supplyMains power supply
Lamp voltage24 - 24 V
Type of control gearElectronic transformer
Exchangeable control gearyes
Energy efficiency class of the light source according to EU regulation 2019/2015C
Degree of protection (IP)IP20
Degree of protection (NEMA)Other
Protection class according to IEC 61140II
Colour of lightWhite
Product codes
SAPDML496
STK4161905
PLC4161905
GTIN/EAN6438171811004
Manufacturer part number81100
Vendor material number81100
Basic information
Package measurements (L x W x H)2600 x 200 x 150 mm
Package volume78 l
Package weight4.5 kg
Base uniteach
Package units1
Package contents–
UNSPSC39111544
BrandSAVO
VendorSAVO DESIGN & TECHNIC OY
