LIGHT KIT SAVO TUDO WHITE 5000MM 4000K
Product code
4161914
The kitchen has a pre-installed wall switch to cut power from the existing distribution box or outlet to which the JOIN converter is connected. The converter's power cable is 2 meters long.
Each end of the LED strip has a 2-meter power cable, allowing the strip to be cut at any desired location.
The JOIN distributor module is connected to the converter, and the LED strip's power cable is connected to the distributor.
The set includes:
JOIN converter
JOIN distributor module
2 pieces of white TUDO aluminum profiles a'2500mm with mounting brackets and end caps
TUDO LED strip 4000K 5000mm (2000mm power cable at each end) This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Light ribbon/-hose/-strip (EC002706)
ModelStrip
Mounting methodSurface mounting
Lamp typeLED not exchangeable
Lamp power per meter11.5 W
Luminaire efficacy173.9 lm/W
Voltage typeDC
Type of power supplyMains power supply
Lamp voltage24 - 24 V
Type of control gearElectronic transformer
Exchangeable control gearyes
Energy efficiency class of the light source according to EU regulation 2019/2015C
Degree of protection (IP)IP20
Degree of protection (NEMA)Other
Protection class according to IEC 61140II
Colour of lightWhite
Product codes
SAPDML487
STK4161914
PLC4161914
GTIN/EAN6438171811202
Manufacturer part number81120
Vendor material number81120
Basic information
Package measurements (L x W x H)2600 x 200 x 150 mm
Package volume78 l
Package weight6 kg
Base uniteach
Package units1
Package contents–
UNSPSC39111544
BrandSAVO
VendorSAVO DESIGN & TECHNIC OY
