CONTACTOR LC1D50AM7 9A 2NC+2NO 42VAC
Product code
3782067
K contactor 9A AC3 42VAC 2 normally closed (NO) + 2 normally open (NC) This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Power contactor, AC switching (EC000066)
Rated control supply voltage AC 50 Hz42 - 42 V
Rated control supply voltage AC 60 Hz42 - 42 V
Voltage type for actuatingAC
Number of normally closed contacts as main contact2
Number of normally open contacts as main contact2
Type of electrical connection of main circuitScrew connection
Operating voltage AC 50 Hz440-440 V
Operating voltage AC 60 Hz440-440 V
Rated operation current Ie at AC-1, 400 V20 A
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as normally closed contact0
Suitable for distribution boardno
Width45 mm
Height58 mm
Depth57 mm
Product codes
SAPDEJ871
STK3782067
PLC3782067
GTIN/EAN3389110488807
Manufacturer part numberLC1K09008D7
Vendor material numberLC1K09008D7
Basic information
Package measurements (L x W x H)65 x 65 x 48 mm
Package volume0.203 l
Package weight0.179 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121529
BrandSCHNEIDER ELECTRIC
VendorSCHNEIDER ELECTRIC FINLAND OY
