CONTACTOR LP4K0910JW3 9A,12VDC
Product code
3782074
K contactor 9A AC3 12VDC 1 normally closed (NO) This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Power contactor, AC switching (EC000066)
Rated control supply voltage DC12 - 12 V
Voltage type for actuatingDC
Number of normally closed contacts as main contact0
Number of normally open contacts as main contact3
Type of electrical connection of main circuitScrew connection
Rated operation current Ie at AC-1, 400 V20 A
Rated operation current Ie at AC-3, 400 V9 A
Rated operation power at AC-3, 400 V4 kW
Rated operation current Ie at AC-4, 400 V6 A
Rated operation power at AC-4, 400 V2.2 kW
Number of auxiliary contacts as normally open contact1
Number of auxiliary contacts as normally closed contact0
Suitable for distribution boardno
Width45 mm
Height58 mm
Product codes
SAPGBJ882
STK3782074
PLC3782074
GTIN/EAN3389110500509
Manufacturer part numberLP4K0910JW3
Vendor material numberLP4K0910JW3
Basic information
Package measurements (L x W x H)65 x 62 x 48 mm
Package volume0.193 l
Package weight0.226 kg
Base uniteach
Package units1
Package contents1
UNSPSC39121529
BrandSCHNEIDER ELECTRIC
VendorSCHNEIDER ELECTRIC FINLAND OY
