CONTACTOR LP4K1201BW3 12A 24VDC 3NO, 1NC
Product code
3860490
TeSys K minikontaktori 12A/5,5kW/AC3, 20A/AC1, 3s pääkosk. 1a apuk. 12VDC 1,8W
TeSys K minikontaktori 12A/5,5kW/AC3, 20A/AC1, 3s pääkosk. 1a apuk. 12VDC 1,8W. tuote tai komponentti tyyppi: kontaktori - laitteen lyhytnimi: LP4K - contactor application: resistiivinen kuorma, motor control.
Product details
Technical specifications
Rated control supply voltage AC 50 Hz0 ... 0 V
Rated control supply voltage AC 60 Hz0 ... 0 V
Rated control supply voltage DC24 V
Voltage type for actuatingDC
Number of normally closed contacts as main contact0
Number of normally open contacts as main contact3
Type of electrical connection of main circuitScrew connection
Rated operation current Ie at AC-1, 400 V20 A
Rated operation current Ie at AC-3, 400 V12 A
Rated operation power at AC-3, 400 V5.5 kW
Rated operation current Ie at AC-4, 400 V6 A
Rated operation power at AC-4, 400 V2.2 kW
Number of auxiliary contacts as normally open contact0
Number of auxiliary contacts as normally closed contact1
Modular versionfalse
Product codes
SAPACF651
PLC3860490
STK3860490
GTIN/EAN3389110791167
Manufacturer part numberLP4K1201BW3
Vendor material number3860490
Basic information
Package measurements (L x W x H)66 x 62 x 48 mm
Package volume0.196 l
Package weight0.21 kg
Base uniteach
Package units1 / 20
Package contents–
UNSPSC39121529
BrandSCHNEIDER ELECTRIC
VendorSCHNEIDER ELECTRIC FINLAND OY
