FREQUENCY CONVERTER IP21 ATV312HU22M2/2,2KW 230V

Variable speed drive ATV312, 2,2kW, 4,4kVA, 123W, 200..240 V- 1-phase supply. range of product: Altivar 312 - product or component type: variable speed drive - product destination: asynchronous motors - assembly style: with heat sink - component name: ATV312 - network number of phases: single phase - line current: 18.4 A for 240 V, 21.9 A for 200 V, 1 kA - EMC filter: integrated - apparent power: 4.4 kVA - asynchronous motor control profile: factory set : constant torque, sensorless flux vector control with PWM type motor control signal - electrical connection: Al1, Al2, Al3, AOV, AOC, R1A, R1B, R1C, R2A, R2B, LI1...LI6 terminal 2.5 mm² AWG 14, L1, L2, L3, U, V, W, PA, PB, PA/+, PC/- terminal 5 mm² AWG 10 - supply: internal supply for logic inputs at 19...30 V, <= 100 mA for overload and short-circuit protection, internal supply for reference potentiometer (2.2 to 10 kOhm) at 10...10.8 V, <= 10 mA for overload and short-circuit protection - communication port protocol: CANopen, Modbus - IP degree of protection: IP20 on upper part without cover plate, IP21 on connection terminals, IP31 on upper part, IP41 on upper part - option card: CANopen daisy chain communication card, DeviceNet communication card, Fipio communication card, Modbus TCP communication card, Profibus DP communication card. Benefits: .. Applications: .. Benefits: The Altivar 31 range is replaced by the Altivar 312 range.. Ease of communication:, Modbus and CANopen integrated as standard, CANopen Daisy Chain, DeviceNet, ProfibusDP, Ethernet/Modbus and Fipio/Modbus gateways... Simplified user interface:, Configuration via mobile phone (Bluetooth®), Intuitive navigation, Local controls on the front panel, Numerous application-specific functions, Auto-tuning for optimum performance, Integrated EMC filter, Rugged for use in all environments, A wide choice of voltage ranges.. Applications: - Handling and packing, Packaging, Textile machines, Special machines, Pumps and fans..
