RELAY CA2KN22G7 120VAC 2NC+2NO
Product code
3782048
Auxiliary contactor 120VAC 2NO+2NC This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Auxiliary contactor, relay (EC000196)
Rated control supply voltage AC 50 Hz120-120 V
Rated control supply voltage AC 60 Hz120-120 V
Voltage type for actuatingAC
Rated operation current10 A
Rated operation current Ie, 400 V10 A
Mounting methodDIN-rail/screw
With LED indicationno
Suitable for manual operationno
Interfaceno
Number of auxiliary contacts as normally closed contact2
Number of auxiliary contacts as normally open contact2
Number of auxiliary contacts as normally closed contact, delayed switching0
Number of auxiliary contacts as normally open contact, leading0
Number of auxiliary contacts as change-over contact0
Operating voltage AC 50 Hz690-690 V
Product codes
SAPCYS832
STK3782048
PLC3782048
GTIN/EAN3389110120721
Manufacturer part numberCA2KN22G7
Vendor material numberCA2KN22G7
Basic information
Package measurements (L x W x H)69 x 63 x 49 mm
Package volume0.213 l
Package weight0.176 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121529
BrandSCHNEIDER ELECTRIC
VendorSCHNEIDER ELECTRIC FINLAND OY
