RELAY CAD50R7 5NC 440VAC
Product code
3782054
Auxiliary contactor 5Su 440VAC This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Auxiliary contactor, relay (EC000196)
Rated control supply voltage AC 50 Hz440 - 440 V
Rated control supply voltage AC 60 Hz440 - 440 V
Voltage type for actuatingAC
Rated operation current10 A
Rated operation current Ie, 400 V10 A
Mounting methodDIN-rail/screw
With LED indicationno
Suitable for manual operationno
Interfaceno
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact5
Number of auxiliary contacts as normally closed contact, delayed switching0
Number of auxiliary contacts as normally open contact, leading0
Number of auxiliary contacts as change-over contact0
Operating voltage AC 50 Hz690-690 V
Product codes
SAPGAM043
STK3782054
PLC3782054
GTIN/EAN3389110403367
Manufacturer part numberCAD50R7
Vendor material numberCAD50R7
Basic information
Package measurements (L x W x H)118.13 x 94.1 x 55.64 mm
Package volume0.618 l
Package weight0.364 kg
Base uniteach
Package units1
Package contents1
UNSPSC39121529
BrandSCHNEIDER ELECTRIC
VendorSCHNEIDER ELECTRIC FINLAND OY
Documents (6)
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)1.2611
GWP, uniteach
Source for GWP dataEPD
Documents (1)
Sustainability brochures & documents
Manufacturer
NameSchneider Electric Finland Oy
Websitehttps://www.se.com/fi/fi/
Postal addressSokerilinnantie 11 C, 02600 Espoo, Finland
