ELECTRONIC BALLAST SENSE 32W 900mA LINECT DA
Product code
4003363
Sense module lights are only 10 mm high. Sense can be installed into visible T-grid ceilings without additional accessories and into concealed T-grid ceilings, DAMPA Clip In ceilings, Troldtekt ceilings, and gypsum board ceilings with additional accessories. Sense is available in different options of 3000/4000 lm (UGR<19) and 5000 lm (UGR<20). LED driver to be ordered separately (phase dimmable, On-Off and DALI). Power can be adjusted via DIP switches. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Ballast (electrical) (EC001497)
ModelElectronic
Dimmableyes
Dimming 0-10 Vno
Dimming 1-10 Vno
Dimming DALIyes
Dimming DALI-2yes
Dimming DMXno
Dimming DSIno
Dimming LineSwitchno
Dimming mains voltage modulationno
Dimming manufacturer's proprietary systemno
Dimming phase cut-off (trailing edge)no
Dimming phase cut-on (leading edge)no
Dimming potentiometer (integrated)no
Dimming programmableyes
Product codes
SAPCJP360
STK4003363
PLC4003363
GTIN/EAN7021988204047
Manufacturer part number820404
Vendor material number4003363
Basic information
Package measurements (L x W x H)310 x 100 x 36 mm
Package volume1.116 l
Package weight0.335 kg
Base uniteach
Package units1 / 20 / 20 / 480
Package contents–
UNSPSC39101904
BrandSG ARMATUREN
VendorSG ARMATUREN OY
Documents (3)
Brochures & documents
Links
Environment and safety
Documents (1)
Sustainability brochures & documents
Manufacturer
NameSG Armaturen AS
Postal addressSkytterheia 25, 4790 Lillesand, Norway
