SENSE ECO 4000K RA<gt/>80
Product code
4241861
Sense module lights are only 10 mm high. Sense can be installed into visible T-grid ceilings without additional accessories and into concealed T-grid ceilings, DAMPA Clip In ceilings, Troldtekt ceilings, and plasterboard ceilings with additional accessories. Sense is available in different options of 3000/4000 lm (UGR<19) and 5000 lm (UGR<20). LED driver must be ordered separately (phase dimmable, On-Off and DALI). Power can be adjusted via the driver's DIP switches. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Ceiling-/wall luminaire (EC002892)
Suitable for wall mountingyes
Suitable for suspended mountingyes
Suitable for ceiling mountingyes
Suitable for built-in mountingyes
Suitable for surface mountingyes
Suitable for light line configurationno
Suitable for workplace according to EN 12464-1no
Lamp typeLED not exchangeable
With light sourceyes
Suitable for number of light sources1
Lamp holderOther
Housing materialAluminium
Surface protection housingPowder coating
Housing colourWhite
Material coverPlastic, structured
Product codes
SAPCJP345
STK4241861
PLC4241861
GTIN/EAN7021982122231
Manufacturer part number212223
Vendor material number4241861
Basic information
Package measurements (L x W x H)597 x 597 x 10 mm
Package volume3.564 l
Package weight3.05 kg
Base uniteach
Package units1 / 4 / 28
Package contents–
UNSPSC39111544
BrandSG ARMATUREN
VendorSG ARMATUREN OY
Documents (8)
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)39.65
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490
