JUNCTION BOX INDUSTRIAL ABOX PRO 025-L/SW
Product code
1622240
Enclosure, Protection rating IP66/IP67/IP69, Nominal cross-section 2.5 mm², Certified VDE (DIN EN 60670-1/-22 (VDE 0606-1/-22)), DLG (ammonia resistance), DNV (class: ships and offshore installations), metric cable entries M16/M20 (1 rear, 7 half), internal mounting points, for installation in industrial environments and unprotected outdoor areas, black, Ui=1000 V AC, without connectors. Dimensions: 92 x 92 x 60 mm. Includes accessories: 4 double membrane seals IP66 M20 sealing range 7–13 mm, lid drop protection This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Box/housing for surface mounting on the wall/ceiling (EC002600)
ModelJunction box
Equipped withNone
Max. conductor cross section2.5 mm²
Number of poles0
Number of clamp positions per pole0
ShapeSquare
Mounting methodWall-/ceiling mounting
Mounting in the soilno
Mounting under waterno
Number of inlets8
Inlet from the rearyes
Length92 mm
Width92 mm
Depth60 mm
Number of cable glands included0
Product codes
SAPDFQ536
STK1622240
PLC1622240
GTIN/EAN4013902662043
Manufacturer part number40200001
Vendor material number1622240
Basic information
Package measurements (L x W x H)92 x 60 x 60 mm
Package volume0.331 l
Package weight0.169 kg
Base uniteach
Package units1 / 60 / 1440 / 3240
Package contents–
UNSPSC39121332
BrandSPELSBERG
VendorSPELSBERG OY
Documents (4)
Environment and safety
Manufacturer
NameGünther Spelsberg GmbH & Co. KG
Websitewww.spelsberg.fi
Postal addressIm Gewerbepark 1, 58579 Schalksmuehle, Germany
