JUNCTION BOX SPELSBERG JUNCTION BOX 2K-16-L/W BLACK
Product code
1622152
Protected rating IP55, nominal cross-section 2.5 mm˛. Internal mounting points for standard indoor installations, black, without connectors.
Features- Ui=400V AC
- Certified VDE (DIN EN 60670-1/-22 (VDE 0606-1/-22))
- Self-sealing, flexible cable gland seals, sealing range 2-14 mm (3 rear, 16 half)
Product details
Technical specifications
Product class (ETIM)Box/housing for surface mounting on the wall/ceiling (EC002600)
ModelJunction box
Equipped withNone
Max. conductor cross section2.5 mm²
ShapeRectangular
Mounting methodWall-/ceiling mounting
Mounting in the soilno
Mounting under waterno
Number of inlets19
Inlet from the rearyes
Length85 mm
Width130 mm
Depth37 mm
Connectableno
Type of housing feed-throughSeal membrane
MaterialPlastic
Product codes
SAPDBY557
STK1622152
PLC1622152
GTIN/EAN4013902685738
Manufacturer part number34621601
Vendor material number1622152
Basic information
Package measurements (L x W x H)37 x 130 x 85 mm
Package volume0.409 l
Package weight0.06 kg
Base uniteach
Package units1 / 5 / 40 / 1680
Package contents–
UNSPSC39121332
BrandSPELSBERG
VendorSPELSBERG OY
Documents (5)
Certificates
Images
Brochures & documents
Links
Environment and safety
Manufacturer
NameGünther Spelsberg GmbH & Co. KG
Websitewww.spelsberg.fi
Postal addressIm Gewerbepark 1, 58579 Schalksmuehle, Germany
