ANTENNA CABLE ECOFLEX 15 PLUS 50ohm Eca
Product code
0204500
No product description available.
Product details
Technical specifications
Diameter inner conductor4,5 mm
Inner conductor materialAluminium
Inner conductor surfaceCopper-plated
Inner conductor categoryClass 2 = stranded
Diameter outer conductor11,3 mm
Outer conductor materialCopper
Outer conductor surfaceBare
Type of outer conductorFoil + braiding
DielectricPolyethylene, foamed (foam PE)
Number of screen layers2
Material outer sheathPolyvinyl chloride (PVC)
Specification material outer sheathOther
Colour outer sheathBlack
Reaction-to-fire according to EN 13501-6: ClassEca
Reaction-to-fire according to EN 13501-6: Smoke productionNone
Product codes
SAPCOM768
PLC0204500
STK0204500
GTIN/EAN6418296000033
Manufacturer part numberECOFLEX15PLUS
Vendor material number0204500
Basic information
Package measurements (L x W x H)1000 x 15 x 15 mm
Package volume0.213 l
Package weight0.167 kg
Base unitMeter
Package units102 / 202 / 505
Package contents–
UNSPSC26121507
BrandSSB
VendorFINNSAT OY
