EMERGENCY LIGHT ZONESPOT II M. TWT9371WT 24-230 VAC/DC IP44 B
Product code
4148820
Zonespot II Midbay is a surface-mounted safety light. The light's optics are designed to provide a wide and uniform light pattern that effectively illuminates open areas. Thanks to its IP43 enclosure rating, Zonespot II is also suitable for humid environments. The light is easy and quick to install on a separate mounting bracket, which also connects the power supply. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Emergency luminaire (EC001957)
Mounting methodCeiling surface mounting
FunctionEscape route lighting
With remote switch connectionno
Lamp typeLED not exchangeable
With light sourceyes
Housing materialPlastic
Housing colourBlack
Voltage typeAC/DC
Nominal voltage220-240 V
Type of control gearLED operating device current-controlled
Exchangeable control gearyes
Light distributorDiffuser lens/optic/panel
Energy efficiency class of the light source according to EU regulation 2019/2015Not required
Degree of protection (IP)IP44
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24yes
Product codes
SAPCYZ466
STK4148820
PLC4148820
GTIN/EAN6438045029108
Manufacturer part numberTWT9371WT
Vendor material numberTWT9371WT
Basic information
Package measurements (L x W x H)180 x 180 x 50 mm
Package volume1.62 l
Package weight0.5 kg
Base uniteach
Package units1
Package contents–
UNSPSC39111709
BrandTEKNOWARE
VendorTEKNOWARE EMERGENCY LIGHTING OY
The country of origin stated by the supplierFinland
Documents (4)
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)6.5
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000490
