EMERGENCY LIGHTING CENTRE TKT6508C
Product code
7118833
TKT65xxCx
The TKT65xxCX series safety lighting center, like all our Tapsa Control centers, automatically handles testing. Suitable for medium and large buildings. Products with IP34 protection class have a product code ending with the letter P.
Technical specifications
The TKT65xxCX series safety lighting center, like all our Tapsa Control centers, automatically handles testing. Suitable for medium and large buildings. Products with IP34 protection class have a product code ending with the letter P.
Technical specifications
- Input voltage 230 VAC
- Output voltage in normal operation 230 VAC
- Output voltage in battery operation 216 VDC
- Battery voltage 216 V, formed by 18 series-connected 12 V batteries
- 8, 16, or 24 group outputs
- Maximum of 16 addressable luminaires can be connected to the same group
Product details
Technical specifications
Product class (ETIM)Central emergency lighting power supply unit (EC002678)
Power2000 W
Wiring systemContinuous circuit/emergency circuit
With remote switch connectionyes
Nominal voltage220-240 V
Degree of protection (IP)IP20
Protection class according to IEC 61140I
Length518 mm
Width239 mm
Height765 mm
Product codes
SAPALU022
STK7118833
PLC7118833
GTIN/EAN6438045006222
Manufacturer part numberTKT6508C
Vendor material numberTKT6508C
Basic information
Package measurements (L x W x H)600 x 800 x 300 mm
Package volume144 l
Package weight32 kg
Base uniteach
Package units1
Package contents–
UNSPSC46171604
BrandTEKNOWARE
VendorTEKNOWARE EMERGENCY LIGHTING OY
The country of origin stated by the supplierFinland
Documents (6)
Brochures & documents
Links
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)89.6
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000569
