LIMIT SWITCH OSISENSE LIMIT SWITCH
Product code
2300486
OsiSense limit switch.
Comprehensive range of limit switches for every need. Wide selection of snap-action contacts for simpler and safer machine design.
Compact range:
- For light and medium-duty applications
- EN50047 products feature positive opening contacts, even in snap-action models, enabling use in safety applications
- XCKP/T/D models with metal head
- XCKN plastic versions for self-resetting machines
Classic range:
- XCKM and XCKL are improved solutions for multi-purpose metal-bodied products
- XCKS plastic housing (EN50041)
Miniature range:
- Compact size
- Ideal for harsh environment machines with limited space
- Same contacts as Compact range applications enable use in safety applications
- XCMN plastic versions for self-resetting machines
Industrial range:
- Heavy-duty use (EN50041)
- XCKJ has the strongest contact in its category
Applications:
- All industrial machines
- Packaging
- Material handling
- Food and beverage industry
- Transportation
- + many others This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)End switch (EC000030)
Width sensor40 mm
Diameter sensor0 mm
Height of sensor77 mm
Length of sensor44 mm
Rated operation current Ie at AC-15, 24 V0 A
Rated operation current Ie at AC-15, 125 V0 A
Rated operation current Ie at AC-15, 230 V3 A
Rated operation current Ie at DC-13, 24 V0 A
Rated operation current Ie at DC-13, 125 V0 A
Rated operation current Ie at DC-13, 230 V0.27 A
Switching functionSlow-action switch
Switching function latchingno
Output electronicno
Forced openingyes
Number of safety auxiliary contacts0
Product codes
SAPGCO238
STK2300486
PLC2300486
GTIN/EAN3666916092125
Manufacturer part numberZCKJ5H7
Vendor material numberZCKJ5H7
Basic information
Package measurements (L x W x H)40 x 44 x 77 mm
Package volume0.136 l
Package weight0.29 kg
Base uniteach
Package units1
Package contents–
UNSPSC39121522
BrandTELEMECANIQUE
VendorTMSS DENMARK APS
