ANTENNA BOX ANTENNA BOX 20 DB TV/R
Product code
7551949
Antenna box to be cascaded 20dB
5-2400MHz
TV-R/SAT This product description is an automated translation of the original Finnish description.
5-2400MHz
TV-R/SAT This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Antenna socket box (EC000439)
ModelLoop-through socket
Type of socket outletTV/RD/SAT
DAB+yes
Mounting methodOther
Number of modules (module system)1
Assembly arrangementBasic element
Tap loss at 860 MHz20 dB
Tap loss at 2150 MHz24 dB
Number of outlets2
Suitable for cable modemyes
Through loss at 860 MHz1 dB
Through loss at 2150 MHz1.2 dB
TV frequency band5 - 1300 MHz
Suitable for remote power supplyyes
Radio frequency band87.5 - 108 MHz
Product codes
SAPCKX642
STK7551949
PLC7551949
GTIN/EAN8424450102800
Manufacturer part numberT5236
Vendor material numberT5236
Basic information
Package measurements (L x W x H)70 x 70 x 27 mm
Package volume0.147 l
Package weight0.07 kg
Base uniteach
Package units1 / 10
Package contents–
UNSPSC43221727
BrandTELEVES
VendorFINNSAT OY
