PRESENCE INDICATOR THERONDA P360-110 DALI UP WH
Product code
2607685
Passive infrared presence detector DALI, 1 lighting channel broadcast, circular monitoring area 360°, Ø 24 m, recessed into a housing, for suspended ceiling installation requires 68A 2607791. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Movement sensor/presence detector complete (EC000133)
ModelPresence detector
Constant light controlyes
HVAC-controlno
Forced switch onno
Forced switch offno
Animal zoneno
Creep-under protectionno
Background monitoringno
Networkableyes
Scan angle360 °
Optimum mounting height2.5 m
Staircase light controlleryes
Bridging switchno
Max. reach sideways12 m
Max. presence range38 m²
Product codes
SAPDHM466
STK2607685
PLC2607685
GTIN/EAN7612748006348
Manufacturer part number2080040
Vendor material number2080040
Basic information
Package measurements (L x W x H)150 x 100 x 80 mm
Package volume1.2 l
Package weight0.225 kg
Base uniteach
Package units1
Package contents–
UNSPSC46171608
BrandTHEBEN
VendorTHEBEN OY
Documents (4)
Environment and safety
Features
Motion sensorYes
