TIME SCWITCH TR 608TOP DIGT 1 KANAV.VRK/VKO

Digital timer with weekly programming: 1 channel, 56 memory locations, DuoFix spring connectors, 2-wire, single-core or multi-core (with or without wire end terminals), wire diameter: 0.5 - 2.5 mm², plug-out button, text-based user interface on display, date and time pre-set. Technical specifications

• mounting method DIN rail
• supply voltage 230-240 V
• protection class IP20
• 24-hour program
• 60-minute program
• weekly program
• holiday program

All functions are available without network connection, connection to OBELISK top2 memory card (PC programming), second switching program from memory card, program copying, program backup, 10-year backup operation (lithium battery), on/off switching times, pre-selection of switching, continuous operation switch on/off, built-in operating hour counter, reset capability, maintenance function for monitoring maintenance intervals. Holiday program, PIN coding, automatic summer and winter time change can be disabled, switching rules for Europe, USA and other countries are already stored, custom switching rules or switching based on fixed dates can be selected.
