TWILIGHT SWITCH LUNA LUNA 126 STAR E AN
Product code
2606628
Theben LUNA 126 Star E is a surface-mounted dimmer switch equipped with a built-in light sensor. The device has a fixed on- and off-delay to prevent false switching caused by flashes or car headlights.
Features
- anthracite color
- surface mounting
- protection class IP56
- light level adjustment range 2–200 lx
- LED load max. 350 W
- fixed on/off delay 20 s / 80 s
- large light detection angle, approximately 180 degrees
- stepless adjustment of switching light level
- electrical wiring possible from back and bottom
- removable cover with latch simplifies installation
- non-removable screws
- large connection space
- light level adjustment from outside without opening the device
Product details
Technical specifications
Product class (ETIM)Twilight switch (EC000189)
Type of sensorBuilt-in light sensor
Contacts1 make contact (NO)
Engaging brightness2 - 200 lx
Switching-off brightness2 - 200 lx
Switch-off delay80 s
Switching-on delay20 s
Max. switching power2300 W
Max. switching power LED350 W
Suitable for C-loadyes
With automatic night switch-offno
Mounting methodSurface mounted
Swivellingno
MaterialPlastic
Material qualityThermoplastic
Halogen freeyes
Product codes
SAPDLU272
STK2606628
PLC2606628
GTIN/EAN4003468120170
Manufacturer part number1260910
Vendor material number1260910
Basic information
Package measurements (L x W x H)140 x 105 x 63 mm
Package volume0.926 l
Package weight0.18 kg
Base uniteach
Package units1
Package contents–
UNSPSC39122206
BrandTHEBEN
VendorTHEBEN OY
