EMERGENCY LUMINAIRE IRIS EMERGENGY LIGHT SELFTEST E3

Iris Antipanic is an independent LED emergency light suitable for recessed installation in 47–85 mm openings. It provides reliable 3-hour emergency lighting with a LiFePO4 battery, and its testing method can be selected via a DIP switch: manual (IEC 60598-2-22) or automatic (IEC 62034). Replaceable optics for corridor (ESC) and open area (ENT) applications are included. Versatile for various emergency lighting needs. The light operates only during emergency situations (non-maintained) and has a service life of up to 50,000 hours (L70). Charging time is 24 hours, and the light consumes only 0.7 W in standby mode. The light can optionally be installed in a surface-mounted housing (accessory). Product specifications:

• Luminous flux: 212 lm
• Color rendering index: CRI ? 70
• Color temperature: 4000 K
• Chromaticity tolerance (MacAdam): 7 SDCM
• Rated service life: L70 50,000 h (25 °C)
• Operating time: 3 h (LiFePO4 battery 3.2 V / 1.6 Ah)
• Charging time: 24 h
• Standby power consumption: 0.7 W
• Charging power: 2 W
• Installation opening: Ø47-85 mm
• Dimensions: Ø140 × 3 mm
• Weight: 0.27 kg
• Protection class: IP2X
• Testing: Manual or automatic testing (SelfTest)
• Installation: Recessed, surface-mounted housing available as accessory.

This product description is an automated translation of the original Finnish description.
