SPEAKER IP HORN SPEAKER

Product code
7914805

The IPS302015-S IP horn speaker is specifically designed for outdoor use, alarm systems, and public address.

It operates seamlessly with Uniview NVR devices.

Features
  • Rated power: 15 W
  • Sound pressure level: 122 dB SPL
  • Frequency response: 300 Hz – 12.5 kHz
  • Impedance: 8 Ω
  • Material: ABS plastic
  • IP66 weatherproof
  • Network protocols: IPv4, HTTP, HTTPS, DNS, SSL/TLS, TCP, UDP, DHCP, UPnP, ARP, SSH
  • Interfaces: ONVIF, RTSP, RTP, LAPI
  • Built-in microphone (100 Hz – 8 kHz, -37 dBV/Pa)
  • Two-way audio
  • Audio file support: MP3, WAV (2 KB – 10 MB)
  • Internal audio storage: 64 MB (up to 100 files)
  • Audio transmission: Scheduled, live, and alarm transmission
  • Audio compression: G.711U
  • Language support: 38 languages, including Finnish
  • Network connection: 1 × RJ45 (10/100 Mbps)
  • Power supply: PoE (IEEE 802.3af) or 12 V DC / 1.4 A
  • Operating temperature: -30 °C – +55 °C
This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Loudspeaker box (EC000652)
ColourWhite
Stand loudspeakerno
Suitable for ceiling mountingno
Suitable for built-in mountingno
Suitable for wall mountingyes
Portableno
Horn speakeryes
Sound barno
Sound projectorno
Frequency300 - 12500 Hz
Impedance8 - 8 Ohm
Music capacity15 W
Nominal capacity15 W
Number of drivers1
Bluetoothno

Product codes

SAPDOM133
STK7914805
PLC7914805
GTIN/EAN6937096346818
Manufacturer part numberIPS302015-S
Vendor material number7914805

Basic information

Package measurements (L x W x H)242 x 185 x 257 mm
Package volume11.506 l
Package weight1.57 kg
Base uniteach
Package units1
Package contents
UNSPSC46171610
BrandUNV
VendorFINNSAT OY

Documents (5)
