FREQUENCY CONVERTER 0100-3L-0023-5-FLOW, 11kW
Product code
3888645
No product description available.
Product details
Technical specifications
Mains voltage380 ... 500 V
Mains frequency50/60 Hz
Number of phases input3
Number of phases output3
Max. output frequency320 Hz
Max. output voltage500 V
Nominal output current I2N23 A
Max. output at quadratic load at rated output voltage11 kW
Number of analogue outputs1
Number of analogue inputs2
Number of digital outputs1
Number of digital inputs6
With control elementtrue
Application in industrial area permittedtrue
Application in domestic- and commercial area permittedtrue
Product codes
SAPCER780
PLC3888645
STK3888645
GTIN/EAN5710108206369
Manufacturer part number136N5044
Vendor material number136N5044
Basic information
Package measurements (L x W x H)480 x 200 x 270 mm
Package volume25.92 l
Package weight11.5 kg
Base uniteach
Package units1 / 8
Package contents–
UNSPSC39121007
BrandVACON
VendorDANFOSS OY AB
The country of origin stated by the supplierFinland
