HEAT RECOVERY UNIT VALLOX 99 CFi RA12
Product code
7912255
- Maximum exhaust air flow 98 l/s @ 100 Pa
- Maximum supply air flow 97 l/s @ 100 Pa
- Constant airflow fans with air flow control
- Airflow control directly from the controller
- Cross-flow heat exchanger, efficiency > 80 %
- Specific energy consumption class (SEC) in cold/average climate: A+/A
- Automatic partial heat recovery bypass with cool recovery
- Vallox demand-based defrost automation
- Automatic boost with internal humidity and carbon dioxide sensor
- Option to remotely control via network by connecting the unit to MyVallox Cloud cloud service or MyVallox Home home network
- Fire damper function
- Supply air filtration ISO Coarse > 75 % + ISO ePM1
- Exhaust air filtration ISO Coarse > 75 %
- Electric afterheater 900 W
- Electric supplementary heater 900 W
- Modbus and KNX interface ready
- Safety switch cuts power when the door is opened
- Water trap Vallox Silent Klick included in price
- Controller included in price
- Wall mounting plate to be ordered separately This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Heat recovery unit (residential) (EC011285)
Heat recovery byOther
Housing materialSteel
Material heat exchangerAluminium
Suitable for wall mountingyes
Suitable for ceiling mountingno
Suitable for floor mountingno
Left/right orientation reversibleno
Type of motorElectronically commutated (EC)
Voltage230 V
Frequency50 Hz
With thermal overload protectionyes
Electrical connectionConnecting cable with plug with protective contact
Energy efficiency class according to 1253/2014/EUA
With digital displayyes
With wired control unityes
Product codes
SAPDMA350
HPAC7912255
PLC7912255
GTIN/EAN6438326005791
Manufacturer part number4128104
Vendor material number7912255
Basic information
Package measurements (L x W x H)660 x 540 x 630 mm
Package volume224.532 l
Package weight65.1 kg
Base uniteach
Package units1 / 6
Package contents–
UNSPSC40161505
BrandVALLOX
VendorVALLOX OY
The country of origin stated by the supplierFinland
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)273.42
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000426
