PRESS PLUG ZN 12 VIEGA
Product code
0485680
V-profile system for industrial and heating equipment use, not suitable for drinking water systems. Connections feature the SC-Contur property, which enables detection of leaks in non-pressurized connections during pressure testing. EPDM O-ring, maximum temperature +110°C, pressure class PN16. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Fitting with 1 connection (EC003023)
Material connection 1Zinc
Material quality connection 1St 34.2 (1.0034)
Surface protection connection 1Untreated
Surface treatment connection 1Untreated
System specificyes
Nominal diameter connection 1Other
Outer pipe diameter connection 112 mm
Connection 1Insert (push-fitting)
Max. operating pressure at 20 °C16 bar
Contour codeV
Material sealingOther
Main colour fittingOther
Length of connection 147 mm
Max. operating pressure at max. medium temperature16 bar
Ring stiffness classOther
Product codes
SAPANB239
HPAC0485680
PLC0485680
GTIN/EAN4015211605308
Manufacturer part number605308
Vendor material number605308
Basic information
Package measurements (L x W x H)45 x 12 x 12 mm
Package volume0.006 l
Package weight0.014 kg
Base uniteach
Package units10 / 400 / 160
Package contents–
UNSPSC40172518
BrandVIEGA
VendorVIEGA CE GMBH & CO. KG
