HOLDING TANK LABKO LOKA 5400 LABKO WITHOUT ALARM
Product code
3629009
Septic tanks are watertight tanks designed for the storage of wastewater or sludge, with no discharge pipe to the environment. When the septic tank is full, it is emptied and the wastewater is transported to a municipal treatment plant. We recommend equipping tanks with an alarm system that indicates when they are full. Ensure compliance with local regulations regarding full-level alarms. This product does not include an alarm.
- cover depth from the top of the tank to ground surface max 100 cm
- minimum distance from the edge of the tank to a traffic area is 2 meters
- if the groundwater level is higher than the inlet, the excavation must be drained or otherwise ensured that groundwater does not rise above the inlet level. For example, in clay soil, a filter fabric/geotextile can be used to prevent soil particle mixing
- minimum installation distance to a slope is 2 m
- the tank must always be anchored using the anchoring lines provided
- geotextile must not be used for anchoring the products.
Product details
Technical specifications
Product class (ETIM)Sewage tank (EC003484)
Material pitPlastic
Material quality pitPolyethylene (PE)
Material coverPlastic
Cover load5 kN
Nominal diameter all connectionsDN 100
Outer pipe diameter all connections110 mm
ConnectionsSlide end
Inner claddingNone
Outer liningNone
Volume class5.4 m³
Wet volume5400 l
Max. negative pressure capacity0 bar
With mud trapno
Dimension free opening315 mm
Number of free openings1
Product codes
SAPANR635
HPAC3629009
PLC3629009
GTIN/EAN6415836290091
Manufacturer part number3065432
Vendor material number3065432
Basic information
Package measurements (L x W x H)2600 x 2430 x 1910 mm
Package volume6100 l
Package weight260 kg
Base uniteach
Package units1
Package contents–
UNSPSC20122802
BrandWAVIN
VendorWAVIN FINLAND OY
The country of origin stated by the supplierFinland
Documents (5)
Brochures & documents
Links
Environment and safety
Features
Made from PVCNo
Warranty (years)1
RecyclableYes
Manufacturer
NameWavin Finland Oy
Postal addressVisiokatu 1, 33720 Tampere
