Product details
Technical specifications
Product class (ETIM)Feed-through terminal block (EC000897)
Connectable conductor cross section fine-strand without cable end sleeve0.5 - 4 mm²
Connectable conductor cross section fine-strand with cable end sleeve0.5 - 2.5 mm²
Connectable conductor cross section solid-core0.5 - 4 mm²
Rated current In24 A
Rated voltage800 V
Type of electrical connection 1Spring clamp connection
Number of levels1
Number of clamp positions per level3
Suitable for conductor materialCopper
Mounting methodDIN rail (top hat rail) 35 mm
Material insulation bodyThermoplastic
Operating temperature-50 - 120 °C
Width5.1 mm
Height64.5 mm
Depth38.5 mm
Product codes
SAPANM942
STK1970264
PLC1970264
GTIN/EAN4008190077327
Manufacturer part number1608540000
Vendor material number1608540000
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume0.017 l
Package weight0.009 kg
Base uniteach
Package units100
Package contents–
UNSPSC39121410
BrandWEIDMÜLLER
VendorWEIDMÜLLER SUOMI
