Product details
Technical specifications
Product class (ETIM)Feed-through terminal block (EC000897)
Connectable conductor cross section fine-strand without cable end sleeve0.5 - 2.5 mm²
Connectable conductor cross section fine-strand with cable end sleeve0.5 - 1.5 mm²
Connectable conductor cross section solid-core0.5 - 4 mm²
Connectable conductor cross section multi-wired0.5 - 2.5 mm²
Rated current In24 A
Rated voltage800 V
Type of electrical connection 1Spring clamp connection
Number of levels1
Number of clamp positions per level2
Suitable for conductor materialCopper
Mounting methodDIN rail (top hat rail) 35 mm
Material insulation bodyThermoplastic
Operating temperature-50 - 120 °C
Width43 mm
Height52 mm
Product codes
SAPANO111
STK1971466
PLC1971466
GTIN/EAN4032248128709
Manufacturer part number1772060000
Vendor material number1772060000
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume0.016 l
Package weight0.006 kg
Base uniteach
Package units100
Package contents–
UNSPSC39121410
BrandWEIDMÜLLER
VendorWEIDMÜLLER SUOMI
