SPRINGTERMINAL 6MM2 BL WKF 6/35 BLUE
Product code
9140663
No product description available.
Product details
Technical specifications
Product class (ETIM)Feed-through terminal block (EC000897)
Connectable conductor cross section fine-strand without cable end sleeve5 - 6 mm²
Connectable conductor cross section solid-core5 - 6 mm²
Rated current In41 A
Rated voltage800 V
Type of electrical connection 1Spring clamp connection
Type of electrical connection 2Spring clamp connection
Number of levels1
Number of clamp positions per level2
Mounting methodDIN rail (top hat rail) 35 mm
Material insulation bodyThermoplastic
Operating temperature-40 - 55 °C
Explosion-tested version 'Ex e'yes
Closing plate requiredno
ColourBlue
Internally connected stagesno
Product codes
SAPAIQ473
STKAIQ473
PLC9140663
GTIN/EAN4015573501621
Manufacturer part number56.706.0053.6
Vendor material number56.706.0053.6
Basic information
Package measurements (L x W x H)0 x 0 x 0 mm
Package volume0.017 l
Package weight0.015 kg
Base uniteach
Package units100
Package contents–
UNSPSC39121409
BrandWIELAND
VendorCABLEX OY
