CIRCULATOR DHW WILO STAR-Z15 NOVA
Product code
4623243
Star-Z Nova is an energy-efficient domestic water pump designed for circulating drinking water systems in industry and building services. Power consumption is only 3-6 W.
Thanks to reliable technology, the pump offers high hygiene safety.
Features
- maximum operating pressure 10 bar
- protection class IP42
- nominal size Rp ˝
- power connection 1~230 V, 50 Hz
- temperature of fluid pumped: drinking water max. +95 °C
Product details
Technical specifications
Product class (ETIM)Built-in circulation pump (EC010980)
Material pump casingBrass
Material quality pump casingDezincification resistant brass (DZR)
Material impeller/pump wheelPolypropylene (PP)
Material quality impeller/pump wheelPP-GF
Volume flow rate (BEP)0.256 m³/h
Discharge head at flow rate (BEP)6.9 kPa
Max. discharge flow0.44 m³/h
Max. static height1.041 m
Max. operating pressure10 bar
Double pumpno
Electrical connectionTerminals
Number of phases1
Frequency50 Hz
Nominal current0.05 A
Motor power input (P1) per motor0 kW
Product codes
SAPAAR089
HPAC4623243
PLC4623243
GTIN/EAN4048482094151
Manufacturer part number4132760
Vendor material number4132760
Basic information
Package measurements (L x W x H)160 x 135 x 115 mm
Package volume2.484 l
Package weight1.038 kg
Base uniteach
Package units1 / 50 / 40 / 280
Package contents–
UNSPSC40151510
BrandWILO
VendorWILO FINLAND OY
The country of origin stated by the supplierFinland
Documents (11)
Images
Brochures & documents
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)7.4736
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000435
