PUMP STRATOS PICO-Z 25/1-6 -180 G40
Product code
4623285
No product description available.
Product details
Technical specifications
Product class (ETIM)Built-in circulation pump (EC010980)
Material pump casingStainless steel
Material quality pump casingCast steel 1.0625
Material impeller/pump wheelPolypropylene (PP)
Material quality impeller/pump wheelPP-GF
Volume flow rate (BEP)2.003 m³/h
Discharge head at flow rate (BEP)36.01 kPa
Max. discharge flow3.5 m³/h
Max. static height5.888 m
Max. operating pressure10 bar
Double pumpno
Rated voltage230 - 230 V
Number of phases1
Frequency50/60 Hz
Nominal current0.44 A
Motor power input (P1) per motor0.04 kW
Product codes
SAPCEO085
HPAC4623285
PLC4623285
GTIN/EAN4048482755106
Manufacturer part number4216473
Vendor material number4623285
Basic information
Package measurements (L x W x H)270 x 178 x 215 mm
Package volume10.333 l
Package weight2.2 kg
Base uniteach
Package units1
Package contents–
UNSPSC40101806
BrandWILO
VendorWILO NORDIC AB
Documents (9)
Environment and safety
Carbon footprint data
Carbon footprint of product manufacturing (A1–A3 GWP value)15.84
GWP, uniteach
Source for GWP dataco2data.fi
Emissions database (co2data.fi) ID7000000435
