PUMPING STATION WILO DRAINLIFT MINI3-XS-EF

Compact, pre-assembled and fully submerged pumping station equipped with a discharge pump. Level measurement is performed using a vertical float switch. Ventilation is integrated into the lid and equipped with an activated carbon filter. Up to four connections are available: - 1 inlet connection 40 mm (DN 40), without check valve, oriented upward, closed at the factory. - 2 inlet connections 40/50 mm (DN 40/50), with check valves, oriented horizontally to the left and right, left open at the factory. - 1 pressure connection 32/40 mm (DN 32/40), with check valves, oriented upward, left open at the factory. Suitable for: collecting and pumping wastewater in domestic environments. Wastewater, not containing fecal matter. Pumping of wastewater in accordance with standard 12050. The sewage pumping station complies with the requirements of standard EN 12050-2. Contents of delivery: - 1 sleeve for HT pipe DN 32/40 (32/40 mm) - 2 hose clamps 32–50 mm - 2 inlet connections DN 50 (50 mm) - 2 sleeves for HT pipe DN 40/50 (40/50 mm) - 2 x check valve - 2 pipe clamps 50–70 mm - 2 hose clamps 32–50 mm - 2 x plug - 6 O-rings - Base mounting (prevents floating): 2 x mounting angle with screws and plugs - Installation and operating instructions This product description is an automated translation of the original Finnish description.
