CAMERA-IP UHD 2K IP65 DC 5V/1A
Product code
7116726
Nothing is more important than the feeling of security, and the WOOX R3568 outdoor camera makes it possible for you. If you are looking for a stylish, high-quality security camera for outdoor use and do not want to compromise on features due to budget constraints, the WOOX-R3568 camera is the right choice for you.
Weatherproof, UV-protected, IP65 certified
The WOOX-R3568 camera is IP65 certified, making it ideal for outdoor use. It can continuously record surveillance footage regardless of changing outdoor conditions, whether it's rain or sunshine. Thanks to UV protection, the camera monitors your home even when ultraviolet rays are particularly strong or the temperature ranges from -20°C to +60°C.
Fixed power cable
Unlike its wireless counterpart, the WOOX-R4260, the R3568 model features a fixed 220V power cable that converts alternating current to direct current, allowing it to be powered via the included 5V power adapter.
Works with WiFi
No additional devices required - the R3568 camera works with any 2.4 GHz wireless router without the need for a separate control unit or paid subscription service.
Two-way audio
Listen and speak anytime, anywhere using the WOOX Home app. The WOOX-R3568 camera features two-way audio functionality, allowing you to ask a courier to leave a package on the porch or scare off potential intruders.
Motion and sound detection
Keep your property under constant surveillance. The WOOX-R3568 camera features motion and sound detection, with live alerts delivered quickly to your WOOX Home app. This helps deter or apprehend intruders.
QHD 2K & Super IR night vision
The WOOX-R3568 outdoor camera rotates 101 degrees horizontally and 90 degrees vertically. Combined with a 104-degree viewing angle, it provides you with complete coverage. The camera is also equipped with a high-quality sensor and a QHD 2K lens, delivering night vision up to 10 meters in complete darkness.
Package contents:
Technical specifications:
Weatherproof, UV-protected, IP65 certified
The WOOX-R3568 camera is IP65 certified, making it ideal for outdoor use. It can continuously record surveillance footage regardless of changing outdoor conditions, whether it's rain or sunshine. Thanks to UV protection, the camera monitors your home even when ultraviolet rays are particularly strong or the temperature ranges from -20°C to +60°C.
Fixed power cable
Unlike its wireless counterpart, the WOOX-R4260, the R3568 model features a fixed 220V power cable that converts alternating current to direct current, allowing it to be powered via the included 5V power adapter.
Works with WiFi
No additional devices required - the R3568 camera works with any 2.4 GHz wireless router without the need for a separate control unit or paid subscription service.
Two-way audio
Listen and speak anytime, anywhere using the WOOX Home app. The WOOX-R3568 camera features two-way audio functionality, allowing you to ask a courier to leave a package on the porch or scare off potential intruders.
Motion and sound detection
Keep your property under constant surveillance. The WOOX-R3568 camera features motion and sound detection, with live alerts delivered quickly to your WOOX Home app. This helps deter or apprehend intruders.
QHD 2K & Super IR night vision
The WOOX-R3568 outdoor camera rotates 101 degrees horizontally and 90 degrees vertically. Combined with a 104-degree viewing angle, it provides you with complete coverage. The camera is also equipped with a high-quality sensor and a QHD 2K lens, delivering night vision up to 10 meters in complete darkness.
Package contents:
- Camera
- USB cable
- User manual
- Power adapter
- Mounting screw pack
- 2x Camera surveillance stickers
- Screwdriver
Technical specifications:
- Power supply: DC 5V/1A (included in package)
- Resolution: QHD 2304x1296P
- IR range: 10m
- Viewing angle: 104°
- Audio IN: Built-in microphone
- Audio OUT: Built-in speaker
- Two-way audio
- Motion detection
- Storage: micro SD card up to 128GB (not included)
- Protocol: WiFi 2.4GHz
- Protection rating (IP): IP65
- Operating conditions: -20 to +60°C, 10%-95% RH non-condensing
- Dimensions: 70x55x163mm
- Maximum transmit power: 16.6 dBm
Product details
Technical specifications
Product class (ETIM)Camera for surveillance system (EC001511)
ModelStandard (Fixed)
Number of pixels (Megapixel)3
With lensyes
Type of interfaceWi-Fi
ProtocolOther
Power over Ethernet (PoE)None
Picture systemPAL
Property picture systemColour
With infrared lightingyes
Max. infrared reach10 m
With video motion detectoryes
Memory capacity0 GB
Number of digital inputs0
Number of digital outputs0
Number of audio inputs1
Product codes
SAPDAX724
STK7116726
PLC7116726
GTIN/EAN8435606735971
Manufacturer part numberWOOX-R3568
Vendor material numberWOOX-R3568
Basic information
Package measurements (L x W x H)178 x 123 x 85 mm
Package volume1.861 l
Package weight0.45 kg
Base uniteach
Package units1 / 20
Package contents–
UNSPSC46171610
BrandWOOX
VendorFINNSAT OY
