SUCTION DEVICE TINOI 100
Product code
8735163
Exhaust air vent designed to match the appearance of the TINO intake air vent. Thanks to its versatile installation options, the TINO series is suitable for a wide range of ventilation solutions. The TINOi exhaust air vent blends into the interior design just like a wall light or audio center. The TINO series is an unobtrusive part of your home's ventilation.
Features:
- Ability to create an architectural element with the TINO intake air vent and the blind TINO-0
- Reliable measurement and fast, precise adjustment
- Meets the latest requirements for fire dampers introduced in 2008
The product is available in both MagiCAD and CADS design software This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Ventilation valve (EC011497)
MaterialSteel
ShapeSquare
Nominal duct diameter connection100 mm
Ring for building inRubber ring
Air supply valveno
Air extraction valveyes
With volume controlyes
ColourWhite
Self-controllingno
Controls, 2 positionsManually operated
High-inducingno
With filterno
Product codes
SAPALK098
HPAC8735163
PLC8735163
GTIN/EAN6415887351635
Manufacturer part number8735163
Vendor material number8735163
Basic information
Package measurements (L x W x H)255 x 42 x 150 mm
Package volume1.607 l
Package weight0.7 kg
Package units1
Package contents1 each
UNSPSC40101503
BrandCLIMECON
VendorCLIMECON OY
The country of origin stated by the supplierFinland
Documents (7)
Brochures & documents
Environment and safety
Origin labelling
Keyflag
The product has the Key Flag Symbol
