SUPPLY AIR DIFFUSER OLO 250-600Z

Highly stylish air diffuser for suspended and cassette ceilings. OLO combines modern and stylish design, high air and acoustic performance, and uniquely easy installation.

The OLO, equipped with adjustable nozzles and designed for higher air volumes, creates a wide, uniformly distributed airflow pattern in the horizontal plane. Thanks to the adjustable nozzles, the OLO’s airflow pattern can be easily modified after installation, for example during space reconfigurations. OLO is suitable for both constant and variable air volumes, and thanks to its high mixing ratio, also for low-temperature supply air.

OLO Z is designed for applications where the underside of suspended ceiling panels is located below a framework formed by T-profiles.

OLO features a patented horizontal adjustability, which significantly simplifies installation. Even if the swirl diffuser is not centered in the ceiling opening after duct installation, it can be precisely positioned without modifying the ductwork, thanks to its horizontal adjustability. This adjustability ensures a clean installation and, in the best case, significantly reduces installation time.

Dimensions

• Řd: 249
• A: 595
• B: 543,5
• H: 81
• L: 565

This product description is an automated translation of the original Finnish description.
