SUPPLY AIR DIFFUSER TINO 125
Product code
8735124
The products of the Elegant TINO series are suitable for various ventilation solutions due to their versatile installation options.
The supply air vent TINO integrates into the interior design just like a wall lamp or audio center. TINO is an unobtrusive part of the home’s ventilation system.
The supply air vent TINO can also be installed farther from the ceiling without creating a draft sensation. The TINO P models also enhance safety in fire situations by limiting the uncontrolled spread of smoke gases between rooms.
The series also includes the exhaust air vent TINOi and the blind design element TINO-0, both representing the same design. This product description is an automated translation of the original Finnish description.
Product details
Technical specifications
Product class (ETIM)Ventilation valve (EC011497)
MaterialSteel
ShapeSquare
Nominal duct diameter connection125 mm
Ring for building inRubber ring
Air supply valveyes
Air extraction valveno
With volume controlyes
ColourWhite
Self-controllingno
Controls, 2 positionsManually operated
High-inducingno
With filterno
Product codes
SAPALK079
HPAC8735124
PLC8735124
GTIN/EAN6415887351246
Manufacturer part number8735124
Vendor material number8735124
Basic information
Package measurements (L x W x H)297 x 50 x 175 mm
Package volume2.599 l
Package weight0.9 kg
Package units1
Package contents1 each
UNSPSC40101503
BrandCLIMECON
VendorCLIMECON OY
The country of origin stated by the supplierFinland
Documents (7)
Brochures & documents
Environment and safety
Origin labelling
Keyflag
The product has the Key Flag Symbol
Sustainability categories
Circular economy
Features
Warranty (years)5
