SUPPLY AIR VALVE CLIMECON LINE 100 BLACK

Product code
8735134
LINE is a quiet, odorless, and domestic intake air vent designed for high-end residential supply and exhaust ventilation. The entire product line features vents with a visible decorative element in either round or square shape, available in painted steel, Accoya® wood, or opal glass. The 100 mm and 125 mm connection sizes are suitable for the most common residential ventilation applications. Features
  • The external appearance of the vents can be easily updated using a specially designed mounting component for customization.
  • Identical-looking supply and exhaust air vents can be installed either on the ceiling or the wall.
  • When installed on a wall, the airflow direction can be adjusted upward using a directional component.
  • Includes a sealed mounting frame and square magnetic adjustment elements (2x2).
  • Even when airflow is restricted, the throw distance does not significantly change, ensuring odorless ventilation in all conditions.
  • The device features a 360° dispersion pattern. Airflow direction of 180° or 270° is possible with an optional LINE-d directional component, allowing the unit to be installed near a wall or in a room corner.
This product description is an automated translation of the original Finnish description.

Product details

Technical specifications

Product class (ETIM)Ventilation valve (EC011497)
MaterialSteel
ShapeRound
Nominal duct diameter connection100 mm
Front diameter205.7 mm
Front width205.7 mm
Front length205.7 mm
Built-in depth19.1 mm
Ring for building inRubber ring
Air supply valveyes
Air extraction valveno
With volume controlyes
ColourBlack
RAL-number9005
Self-controllingno
2-position settingno

Product codes

SAPCNX911
HPAC8735134
PLC8735134
GTIN/EAN6415887351345
Manufacturer part number8735134
Vendor material number8735134

Basic information

Package measurements (L x W x H)225 x 215 x 70 mm
Package volume3.386 l
Package weight0.65 kg
Base uniteach
Package units1 / 13 / 260
Package contents
UNSPSC40101503
BrandCLIMECON
VendorCLIMECON OY
The country of origin stated by the supplierFinland

Environment and safety

Origin labelling

Keyflag
The product has the Key Flag Symbol

Sustainability categories

Circular economy
More Sustainably Produced

Features

Warranty (years)5

Carbon footprint data

Carbon footprint of product manufacturing (A1–A3 GWP value)2.8034
GWP, uniteach
Source for GWP dataEPD

Documents (1)

Sustainability brochures & documents
